Lithium Ion Rechargeable Cell: Sonata® 5300 3.65V 5300 mAh (19.3Wh) - UN38.3 Passed

Your Price: We do not sell single cells. For battery pack only !
Out of stock

Product ID # 9266
Part Number:
LC-SONATA5300

Personalizations

* denotes required field

Add Tabs ? *


Boston-Power’s Sonata 5300 is a high performance lithium-ion rechargeable cell. Its exceptional energy density, industry-leading cycle life, fast charge c apability, and industry leading safety features mak e the Sonata 5300 an ideal solution for industrial, medical, military, notebook computer sensor, and other portable power applications.

Product

Sonata 5300 Rechargeable Lithium-ion Cell

Nominal capacity

5300 mAh

Nominal energy

19.3 Wh

Nominal voltage

3.65V

Energy density

  • Gravimetric 202 Wh/kg
  • Volumetric  490 Wh/L

Nominal cell impedance (1kHz, AC)

23 m Ω

Cycly life to 80% capacity

>1000 cycles

Standard charging method

  • Constant current (CC): 3.7V (0.7C) to 4.2V
  • Constant voltage (CV): 4.2V to 50 mA

Recommended fast charge

8.0A (1.5C) to 4.2V

Nominal cell weight

95 g (3.35 oz)

Discharge current

Max: 7.95A

Operating Temperature

  • Charge: -20°C (-4°F) to +60°C (140°F)
  • Discharge: -40°C (-40°F) to 70°C (158°F)

Storage Temperature

-40°C (-40°F) to +60°C (140°F)

Dimension(LxWxH)

65.2mm(2.57") x 19mm(0.75") x 37.1mm(1.46")

Certifications

UN 38.3, UL1642, IEC 62133, ROHS 2002/95/EC
Nordic Ecolabel 330011

Specification

Warnings

California residents: Warning: Cancer and Reproductive Harm - See Prop 65 Warnings
