Category : High Power Polymer Li-Ion Cells

Picture  Part # Capacity (LxWxH) mm
with tolerance +/- 1 mm
Weight Max Disch. Current
PL-1055275-2C 21Ah 275x55x10.5 406g 42A
* PL-9759156-10C 10Ah 160x61x10.5 207g 100A
* PL-9759156-5C 10Ah 160x60.5x10.4 210g 50A
PL-8048168-5C 6.4Ah 168.5x48.5x8.0 140g 32A
* PL-6745135-10C 4.0Ah 136x45x7.0 90g 40A
* PL-6050140-10C 4.0Ah 141x50.2x6.0 85g 40A
PL-7035130-10C 3.0Ah 130x35.5x7.4 65g 30A
PL-6045135-10C 3.0Ah 135x45.5x6.0 71g 30A
PL-803496-25C 2.2Ah 96.5x34.5x8.0 52g 55A
PL-604490-20C 2.1Ah 90.5x44.5x6.0 46g 40A
PL-603495-10C 1.9Ah 97x34.5x6.2 40g 19A
PLH-703562-10C 1.4Ah 65x35x7.0 65g 10-20A
PLH-355585-7C 1.5Ah 85x55x3.5 31.2g 10A
PLH-553562-10C 1.05Ah 62x35x5.5 18g 10A
PL-603048-10C 750mAh 52x30.5x6.2 14g 7.5A







Displaying products 1 - 13 of 13 results
---------------------------
What to consider when designing Lithium Batteries?
---------------------------
Bluetooth Technology for Lithium-ion/LiFePO4 Batteries
---------------------------
UN 38.3 Safety Test

We own a national standard UN38.3 testing lab. We can provide UN38.3 test service to our customer.

If you want to set up your own lab, we also provide UN38.3 & IEC62133 equipments and onsite training. Email us for the quote and lead time.
---------------------------
Lithium Battery Shipping Regulation
---------------------------
Recommendations on How to get ≤30% Rated Capacity for Shipping
---------------------------
Thermal Abuse Test for IEC62133
