Custom Li-Ion 18650 Battery: 29.2V 5.2Ah (152Wh, 5A rate, 2x8S/S, LR1865SK)


Your Price: $168.00
Build to order

Product ID # 4621
Part Number:
CU-JAS259

Lead Time: 5-7 Business Days / Hazmat handling fee required*

Quantity Discounts

QuantityAmount
5 to 19$162.96
20 to 49$159.60
50 to 99$156.24
100 or more$151.20

Features

Update on 10/27/2021
  • Previous cell discontinued, updated to use LR1865SK.
*Important Shipping Regulation This pack is for testing (prototype) only. It has not been UN38.3 tested yet.  Read more...
Battery
  • 29.2V 5.2Ah Li-Ion Battery pack is made of 16pcs 18650 2600mAh cells and packed in 8S2P
  • 8x2 row configuation
  • Black PVC
Voltage                            Nominal: 29.2V;  Maximum Charge Voltage: 33.6V;  Discharge Cut off: 22V
Capacity 5200 mAh
Protection
  • 1x 8S board (5A limited) PCM-SM17-29.6  installed with the battery pack and protects the battery from
    • Overcharge / Over discharge / Over drain / Short circuit
  • No polyswitch - requested by the customer
Terminals 6"' 14AWG open end wires
Charge Current Maximum: 2400mA
Discharge Current Maximum: 5000mA
Dimensions(LxWxH) 145mm(5.71") x 45mm(1.77") x 65mm(2.56")
Weight 1LB 11OZ (754g)
