Custom Li-ion 18650 Battery: 14.4V 6.7Ah (96.48Wh, 9A rate, 8S/S, NCR18650B) with Fuel Gauge

Your Price: $145.88
Build to order

Product ID # 11145
Part Number:

Lead time 5-10 Business Days


*Important Shipping Regulation This pack is for testing (prototype) only. It has not been UN38.3 tested yet.  Read more...
Voltage Nominal: 14.4V; Charge Cut-off: 16.8V; Discharge Cut-off: 10V
  • Norminal: 6700mAh
  • 6.0" 22AWG open end wires
    • Red = +
    • Black = -/10k
    • White = 10k
  • Fuel gauge
  • 1 x PCB (10A) installed with the battery pack and protects the battery from
    • Over-charge / Over-discharge  / Over-drain/ Short circuits
  • 1 x 9 Amp polyswitch installed to limit  max. discharging current at 9A and to protect wrong polarity
  • 1 x 10K Thermistor
Charge Current ≤3250mA / 0.5C
Max. Discharge Current 9Amp limited by polyswitch
Dimensions(LxWxH) 146mm(5.7”)x22.5mm(0.9”)x66mm(2.6”)
Weight 396g  ( 14.0Oz )
Temperature        Charge: 0 to 45°C
       Discharge: -20 to 60°C
       Storage: -20 to 50°C



  • Li-Ion battery may be exploded if misusing. We are not responsible for any damages or losses caused by misusing (included but not limited to: improperly charging/discharging, any changes of this battery pack, misassembling battery packs) .
  • Always charge battery with attention.
  • Please check battery polarity before plug battery into device
  • For safety warning please see the link here
