Category : 1- 2 C Rate Polymer Li-Ion Cells

  Picture   Part #  Capacity   LxWxH(mm) with tolerance ± 1 mm  Weight Max Discharge
PL-1055275-2C 21Ah 275x55x10.5 406g 42A
PL-8570170-2C 12.6Ah 171x70x9 240g 25A
PL-9059156-1C 10Ah 160x60.5x10 200g 10A
PL-809797-1C 9Ah 100x100x8 164g 9A
PL-7548168-1C 6.4Ah 169x49x7.5 120g 6.4A
PL-7250115-2C 5.0Ah 117x50x7.2 90g 5.0A
PL-896474-2C 5.0Ah 75.5x64.5x9 85g 5.0A
PL-6767100-1C 5.0Ah 99x68.5x6.8 95g 5A
PL-5467100-2C 4.25Ah 101.5x67.5x5.8 85g 8.5A
PL-5545135-2C 3.65Ah 136x45x5.5 75g 7.3A
PL-655585-2C 3.2Ah 86.5x55x6.5 85g 6.4A
PL-544792-2C 2.5Ah 95x47x5.4 51g 5.0A
PL- 605060-2C 2.0Ah 60.5x50.5x6 40g 4.0A
PL-425085-2C 1.8Ah 86x50.5x4.1 37g 3.6A
PL-325085-2C 1.5Ah 85.5x50.5x3.2 28g 3.1A
PL-703562-2C 1.5Ah 68x35x6.8 28g 3.0A
PL-383562-2C 800mAh 68x35x4 18g 1.6A
PL-503048-1C 700mAh 48.5x30.5x5 11.5g 0.7A
PL-503035-2C 530mAh 35x30.5x5 10.0g 1.2A
PL-402248-2C 400mAh 49x22.5x4.1 9.5g 0.8A
Displaying products 1 - 20 of 20 results
---------------------------
What to consider when designing Lithium Batteries?
---------------------------
Bluetooth Technology for Lithium-ion/LiFePO4 Batteries
---------------------------
UN 38.3 Safety Test

We own a national standard UN38.3 testing lab. We can provide UN38.3 test service to our customer.

If you want to set up your own lab, we also provide UN38.3 & IEC62133 equipments and onsite training. Email us for the quote and lead time.
---------------------------
Lithium Battery Shipping Regulation
---------------------------
Recommendations on How to get ≤30% Rated Capacity for Shipping
---------------------------
Thermal Abuse Test for IEC62133
