Smart Fast Charger (1.2A) for 6.4V LiFePO4 Battery Pack (7.6V cut-off) --- CE/UL Listed

Your Price: $12.95
Out of stock

Product ID # 3286
Part Number:
CH-LF6412



Quantity Discounts

QuantityAmount
5 to 20$12.56
21 to 50$12.30
51 to 100$12.04
101 or more$11.66

Features

Feature
  • Smart charger designedto charge 6.4V LiFePO4 battery pack with capacity >= 1200 mAh
  • CCCV charging mode, and power off when battery voltage reaches 7.2V
  • Stabilized output, low ripple
  • Charge time = (Ah rate of the pack x 1.41) / 1.2A charge current
Input Voltage 100- 240VAC, 50/60 Hz
Input Power 9.0W Max
Output Voltage 7.2 VDC
Charging current 1.2A
Protection Short Circuit / Over-voltage / Output-reversed Protection
LED Indicator
  • Red LED = charging
  • Green LED = fully charged
Connector
Accessories Included 1 x Connector Adaptor: from 5.5mm x 2.1mm female Barrel plug to Clips
Size (LxWxH) 88mm(3.5") x 52mm(2.0") x 30mm(1.2")
Weight 4.9 Oz (139 grams)
Certification CE / UL Listed

Warnings

  • Do not expose the product to rain or humidity to prevent from electric shock
  • Charge 6.4V LiFePO4 rechargeable battery >= 700mAhonly
  • It is normal if the product gets slightly hot in using
  • Keep the product out of the reach of children
  • Do notopen the charger and touch any part of the product to prevent from electric shock
