SLA Battery:Regulated Sealed Lead Acid Battery 12V 12Ah with Overcharge and Overdischarge Protection

Your Price: $59.98
In Stock

Product ID # 4013
Part Number:
SC-10AC01



Quantity Discounts

QuantityAmount
5 to 20$58.18
21 to 50$56.98
51 to 100$55.78
101 or more$53.98

Features

  • 1 x 12V 12Ah Lead Acid Battery with DC Voltage Controller (120W ) for Solar Panel
  • SR-L2410A DC voltage controller is installed on top of the battery
    • Connect a 15V 2A AC-DC adaptor or  12C solar panel  to the controller,  power can be cut-off power when 12V SLA battery is full
    • Protect battery from overcharged and over-discharged to increase battery service life
    • LED display battery storage level
    • Built in fuse to protect short circuit and wrong polarity connection
    • Moisture proof design for outdoor use
    • Stable 12VDC output without influence of battery voltage change
    • Included 3 terminals
      • DC input port ( 2 left-most terminal)
      • Optional: 12V SLA battery port (Use to charge additional battery (2 middle port).
      • 12VDC output port. (2 right-most port)
  • Easy to install, see picture below:
  • Smart Battery's Dimension (LxWxH): 156mm (6.1") x 100mm (3.9") x 128mm (5.0")
    Charger Controller's Specifications
    • Solar Panel Require:           12-17V  < 170W
    • Battery Require:                12V/24V SLA, 12.8V/25.6V LiFePO4 battery > 7Ah
    • Output Voltage:                 12V/24V DC (same as battery voltage)
    • Max. working current:         10Amp
    • Overload protection:           >15A for 5 sec. and 30A if short circuit
    • Self Discharge rate:            <= 6 mA
    • Charging voltage drop:       <0.26V
    • Discharging voltage drop:    < 0.15V
    • Over-voltage protection:      17V/ 34V
    • Low battery protection:        <11.1V / <22.2V
    • Smart charging:                  Three stages floating mode
    • Max Dimension (LxWxH):    140mm (5.5") x 91mm (3.6") x 27mm (1.1")
    • Weight:                              250 grams (9.0Oz)
    • Working temperature:          -25oC - +55oC
    • Enclosure:                           PI22 water proof, ABS materials
    • Warranty:                            Two years
    • Please download the specification here
    • Download user manual

    Related Products

    Related Products

    Product Reviews

    (1 Rating, 1 Review) Average Rating:
    ratingratingratingratingrating
    ratingratingratingratingrating
    Still working after 4 years!
    Tom Fell (Black Mountain, NC) 9/3/2013 3:40 PM
    This little combination was my intro to solar power over 4 years ago. While I have moved on to bigger charge controllers and batteries, this unit is still in daily use operating an LED porch light for about 5-6 hours a night (every night). I use it along with a 20 watt solar panel and I couldn't be happier with it's performance.
    ---------------------------
