LiFePO4 26650 Battery: 3.2V 158.4Ah (506Wh, 100A rate ) (47.52)
|
|
In Stock
Product ID # 4995
Part Number: LFP-3.2V158.4Ah
Lead Time: 5 Business Day
Quantity Discounts
| Quantity | Amount |
| 5 to 20 | $480.10 |
| 21 to 50 | $470.20 |
| 51 to 100 | $460.30 |
| 101 or more | $445.46 |
|
| Packing
|
|
| Voltage
|
Voltage: 3.2 V (working) 3.8 V (peak) 2.5 V ( cut-off)
|
| Capacity
|
158.4Ah (506.88Wh)
|
| Cycle life
|
> 1000 cycles (80% of initial capacity at 0.2C rate, IEC Standard)
|
| Energy Density
|
|
| Prewired
|
- 8" long 6 AWG open end wire
- Red = Positive
- Black = Negative
|
| Charging rate
|
6.0A Max
|
| Max. Discharging Rate
|
- 100Amp limited by 6AWG wire
- Higher drain rate avialable upon requested
|
| Dimensions (LxWxH)
|
- 158mm(6.2") x 110(4.3") x 139 (5.5") .
|
| Weight
|
|
| Smart Tips
|
|
| Applications
|
- A Perfect 3.2V Battery module with 100A Max drain rate for EV, HEV application
- You may build battery pack for higher voltage (series connection) or higher capcity (parallel connection)
|
| Warning
|
- 3.2V LiFePO4 battery pack shall be cut-off at 3.8V during charging and 2.5V during discharging. If over discharge to 2.5V, please recharge the pack right away. Otherwise the battery is over discharge and cannot recover!
- Please click Knowledge on LiFePO4 batteryto learn more detail
|
|
