LiFePO4 18650 Battery: 12.8V 1500 mAh (5.5 mm x 2.1 mm Male Barrel plug, 19.2Wh, 4A rate with PCB) (1.8)

Your Price: $41.50
In Stock

Product ID # 4410
Part Number:
LFP-1500-4S

Lead Time: 5 Business Days!


Quantity Discounts

QuantityAmount
5 to 20$40.25
21 to 50$39.42
51 to 100$38.59
101 or more$37.35

Features

*Important Shipping Regulation This pack is for testing (prototype) only. It has not been UN38.3 tested yet.  Read more...
Packing
Voltage 12.8 V (working)   15.6 V (peak)  8.0 V ( cut-off)
Capacity 1500 mAh (19.2Wh)
Cycle Life   >1000cycles (80% of initial capacity @ 0.2C rate, IEC Standard)
Protection
  • One PCB (7A) installed with the  battery pack and protects the battery from
    • Overcharge       (>15.6V)
    • Over discharge  ( <8.0 V)
    • Over drain ( > 7 Amp)
    • Short circuits
  • One 4.2 Amp polyswitch installed to limit  max. discharging current at 4.2A and to protect wrong polarity
Prewired
Charging rate 0.5 A ( recommended ), 1.5A Max
Max. Discharging Rate 4.2Amp limited by polyswitch ( lower rate available upon request )
Dimensions(DiaXH) 26mm(1.0") x 270mm (11.0")
Weight 6.7 oz (190 grams)

Applications

  • 12V Bike lighting up to 15 W halogen light
  • External battery pack to run 12V DC devices, such as digital camera or camcorder
  • 12V LED light (5.5mm x 2.1mm Female Barrel plug) system as picture shown below.
  • Burn-time = (32.4Wh / Device's wattage)

Warnings

  • This 12V LiFePO4 battery pack  did not install PCB, and it  shall be cut-off at 14.4V during charging and 10.0V during discharging
  • Please click Knowledge on LiFePO4 battery to learn more detail
