Hi-Power LiFePO4 Li-Ion Module: 30V 20Ah (10x2R Pack, 600Wh, 45A rate ) Prewired with polyswitch
|
|
In Stock
Product ID # 4296
Part Number: LFPO4-30V20Ah
Quantity Discounts
| Quantity | Amount |
| 5 to 20 | $882.21 |
| 21 to 50 | $864.02 |
| 51 to 100 | $845.84 |
| 101 or more | $818.55 |
|
| Packing
|
|
| Voltage
|
Voltage: 32 V (working) 38 V (peak) 25 V ( cut-off)
|
| Capacity
|
20Ah (600Wh)
|
| Protection
|
- 5 pcs 9 Amp polyswitches installed to limit max. discharging current and to protect wrong polarity
|
| Prewired
|
- 8" long 10 AWG open end wire
- Red = Positive
- Black = Negative
|
| Charging rate
|
5A Max
|
| Max. Discharging Rate
|
45 Amp limited by polyswitches ( lower rate available upon request )
|
| Dimensions (LxWxH)
|
440mm(17.3") x 100(3.9") x 145 (5.7")
|
| Weight
|
7800 grams (17.2 lb)
|
| Smart Tips
|
|
| Applications
|
- External battery pack to run 30V DC devices (45A Max Current load)
- Need connector for DIY? Please click here to order
- Calculate Burn-time = 600Wh / Wattage of device.
|
| Warning
|
- 30V LiFePO4 battery pack shall be cut-off at 38V during charging and 25V during discharging
- Please click Knowledge on LiFePO4 batteryto learn more detail
|
|
