Custom 12.8V 400Ah LFP pack with custom BMS and Smart load/charge board

Your Price: $3,742.00
Out of stock

Product ID # 10110
Part Number:
CU-J1178

Lead Time: 15 Business Days

Personalizations

* denotes required field

Description of Pack:*
Enter description of the pack you need100 characters remaining


*Important Shipping
Regulation
 This pack is for testing (prototype) only. It has not been UN38.3 tested yet. Read more...
Packing
  • Made of  2 x  12.8V 200 Ah LFP pack (part no: LFP-G4S200Ah in parallel
  • 2 x BMS-BBS-300  is a custom BMS board that support upto 4 cells at 300A discharge, Balance, over charge and ove discharge protection and support of Bluetooth Low Energy (BLE) to Android device
  • 1 x Smart load/charge  board to allow auto select upto 4 charge input
Voltage 12.8 V (working)   15.2 V (peak)  10.0 V ( cut-off)
Capacity 400Ah (5120Wh)
Cycle life >1000 cycles (80% of initial capacity @ 0.2C rate, IEC Standard)
Terminal
  • Screw terminal, which may be varied based upon availability
    • 4 x 2.5mm & 1 x 4.0mm Hex screw Terminal
    • Included 4 pcs
Charging rate
  • Standard charging current 1C rate (200A)
  • Max charging current <3C (500A)
Max. Discharging Rate
  • Constant discharge current: 600A (3C rate)
  • Impulse discharge current (<10sec): 2000A (10C rate)
Dimensions(LxWxH) Battery Diminsion: 500mm(19.7") x 142 mm(5.5") x 259mm(10.1")  x 2
Weight Gross Weight: 50Kg (110lbs )
Shipping Weight: 130LB (Must ship by Pallet) or will call
Note International Customers: Due to the high shipping cost , we are sorry we do not issue warranty, return or refund for this item. You are buying at your own risk.
