• 100-240V AC input for worldwide use.
• The charger can cut-off power Automatically by negative delta V IC when battery pack is fully charge.
• Battery will be charged at 2Amp current.
• Approx, Charging time( hours) = Battery capacity ( Ah) / charging current ( A).
• Protection fuse for over current, short circuit & reverse polarity protection.
• Charging time can be estimated as the follow:

Charging time ( Hrs ) = Battery capacity ( mAh) / Charging current ( 0.6A or 1.2A )

• One standard Tamiya male connector installed with the charger.
• One set connector adaptor from female tamiya to Clips is included for charging any battery packs.
• One temperature sensor is included, which must be plugged to battery charger and be attached to battery pack before charging to protect battery overcharging or explode. We are not responsible for any damage caused by miss use.
• It is a very smart charger. Just plug it in and wait for the battery to get charge.
• The charger is designed for taste charging any 19.2V - 24V Nicd and NiMH battery packs. Ideal for 19.2V - 24V battery pack for E-bike, E- scooter and hunting light
• Dimension: 2.0"H X 2.7"W X 5.8"L.
• Weight: 15 OZ.

Temperature Sensor Usage:

The temperature sensor included with the charger must be attached firmly to 24V battery pack as shown below, to double ensure battery pack from overcharging:

Precautions:

• Please don't use the 19.2V-24V charger for charging battery pack with voltage <19.2V or voltage >24V and capacity <1800 mAh
• The charger is designed for indoor use only.
• Battery pack must be made by high drain current cell.
• Please contact your seller for any damage and consequent damage by misusage.
• The charger should be horizontally positioned and work in well ventilated condition, avoid wet and keep it away from inflammable explosive goods.
• Don't cover the charger when charging. ambient temperature shall not be more than 40 degree.
• Cut off the power supply before connect or disconnect the charger with batteries. Always make sure battery polarity is connected correctly
• Don't try to disassemble the charger high voltage inside, danger!
