Li-ion 18650 Battery: 3.7V 10.4 Ah Battery Module with PCB (3.12)

Li-ion 18650 Battery: 3.7V 10.4 Ah (38.48wh) Battery Module with PCB


Packing
  • 3.6V 10.4 Ah Li-Ion Battery Module with protection IC which is built by 4 pcs High quality Sanyo/LG/Other Top Brand Korea 2600mAh Li-Ion 18650 Cells connected in parallel
  • The battery pack is wrapped by white PVC shrink tube
Voltage Voltage: 3.6V (working) 4.2V ( peak) 2.5V ( cut-off)
Capacity 10.4 Ah min. (38.5 wh)
Protection
  • One PCB (8.5A) installed with the battery pack and protects the battery from
    • Overcharge (>4.2V)
    • Overdischarge ( < 2.5 V)
    • Over drain ( > 8.5 Amp)
    • Short circuits
  • 7 Amp polyswitchhes installed to limit max. discharging current at 9 A and to protect wrong polarity
Pre-wired
  • 6" length 22 AWG wire installed with battery pack without connector
  • Need a connector, please find one here
Max. Discharging Rate 7Amp limited by polyswitch
Dimensions

2.9"L x 2.5"W x 0.75"H.

Weight 6.8 oz
Smart Tips

You can use our Smart Fast Charger (3.0A) for 3.7 V Li-ion Rechargeable Battery Pack to recharge the battery pack, charge time is about 5.2 hours.

Applications
  • It is ideal for memory buck-up, external battery bank for MP3 etc
  • You may connect two module in series to form a 3.7V 19.6Ah battery pack
Warning
  • Please note this battery is for R&D use only and NOT for individual customers. We are not responsible for any damages or losses caused by using the battery pack
  • Please never discharge the battery pack beyond its Max. rating
  • Must read here before place an order. Please download fill the form and fax back to 510-439-2808. Attn: BatteySpace-Tech. We reserve the right to not sell the battery to any one if we feel they cannot handle Li-Ion battery safely
  • For safety warning please see the link here
Price: $58.95
Buy Product Online | Visit Store Home
