Those batteries cluttering up drawers in your home-are they good, dead, or what? This battery rack lets you store and organize all unused household batteries in one handy place, and even includes a built-in battery tester so you know which ones you shouldn't even bother storing! Stores up to 66 batteries (AA, AAA, C, D, 9v, and Button Cell sizes), and even has labels for "charged" or "discharged" rechargeable batteries. Housing fits drawer, cupboard, or can be wall-mounted (screws included). Battery Rack with Tester meter! Mounting hardware included.
Battery Rack can hold up to:
- 10 - AAA batteries
- 25 - AA batteries
- 8 - 9V batteries
- 10 - C batteries
- 8 - D batteries
- 5 - Button cell batteries (Top drawer) (5 Button Cell Batteries are not included in this Combo)
About 61 NIMH Rechargeable Batteries:
- Various sizes of high quality Powerizer NiMH batteries are included (61 pcs) for your every application:
Testing batteries:
- Batteries maybe tested with the meter/tester in the rack, or it may be removed from the rack for convenience.
- To test AAA, AA, C, D and Button Cell Batteries, lift the arm of the tester and place the battery so that the bottom touches the contact in the swing arm. This is shown in the line drawing on the rack.
- To test 9V batteries hold the contacts against the meter terminals on the right. There are one large and one smaller hole that match the 9V battery contacts.
Warning:
- Dispose old batteries promptly and properly.
- Keep batteries out of the reach of children.
- Swallowing a button cell battery is extremely dangerous.
About the V2299 Smart Charger:
Easy to use. One for all size rechargeable NiMH / NiCd batteries
Powered by an external AC adapter (In-put: 110V output: 12VDC 1000mA).
Intelligent microprocessor controlled to cut off power automatically once battery get fully charged.
Battery life well protected by negative delta V (- delta V) detection, and time protection of AAA, AA, C & D size batteries.
Use constant current pulse charging system
Recharges NiMH / NiCd batteries at a time for 2 pcs or 4 pcs AA / AAA /C/D and 1-2 pcs of 9V cells
Automatic charge/discharge current selection for the different size of batteries.
LED display for rapid charge / trickle charge / bad cell detection for AA, AAA, C & D size batteries:
- Red LED --- Rapid charge
- Green LED --- Cell are ready for use / trickle charge
- Flashing RED LED --- cells are not suitable for charging
- For 9V batteries: RED LED --- charging
Packing: Each in a gift box with Powerizer logo
Measurements: 5.0"W x 6.7"L x 2.5"H.
Weight: 2.0 lbs
CE & UL approved.
ROHS Compliant
 Please click here to download the instruction manual of the charger
Charging time: One times fully charge the following of battery.
- AAA size: capacity: 600-1000mAh; Charging time: 1.5 - 3 hrs.; Charged by constant current at 400mA.
- AA size:capactiy: 800 -2600mAh; Charging time: 1- 3 hrs. Charged by constant current at 850mA
- C size: capacity: 1200 -5500mAh; Charging time: 2 - 7 hrs. Charged by constant current at 850mA.
- D size:capacity: 1.2 -10 Ah; Charging time: 2- 14hrs. Charge by constant current at 850mA.
- 9V block size: capacity: 100mAh-250mAh; Charging time: 9-18 hrs. Charged by constant current at 16mA.
FAQ: What is different between V2299 smart charger and B1HU ?
- V2299 and B1HU both are advanced Smart Chargers, but V2299 has lower cost, please see below to see different
| Smart Charger Differences |
V2299 |
B1HU |
| Can it charger single cell |
No |
Yes |
| Does it has discharging function? |
No |
Yes |
| Which one is charging faster? |
same |
same |
| Which one has lower cost ? |
Lower |
higher |
Suggestion: If you don't need to charge single (1) cell and/or discharge battery ( in most of case for NiMH ), you can use V2299 instead of B1HU to save some money
|
