Equipment: ZDBX-1 Automatic Digital Wire Cutting & Stripping Machine - CE

Your Price: $2,250.00
In Stock

Product ID # 5811
Part Number:
ZDBX-1

Call for availability!


ZDBX-1 is an automated computerize cutting & wire stripping machine for processing single core wire from both sides. (Excluded 18AWG Red from picture)

Feature
  • Complete management of all processing parameters
    • Wire length (mm)
    • Wire size (AWG)
      • Applicable size: 18AWG - 30AWG
    • Cutting and stripping length (mm)
    • The number of cutting wire required for each process
    • The total number of cutting wire required for the whole process
  • Wire Type:PVC, Teflon, VSF, IV, KVm Glass wire
  • Innovative keyboard placed on control panel
  • Large LCD display for view data setting
  • High quality cutting
    • Cutting length: 1.0mm ~ 99999mm
  • Precision & Repeatability for insulation incision and stripping (Full stripping, Semi Stripping, Mid Stripping)
  • Need a Wire (Without Cut & Stripping)? Please click here to order separately.
  • Need a Wire (Cut & Stripping Single End)? Please click here to order separately.
  • Need a Wire (Cut & Stripping Both End)? Please click here to order separately.
  • Quick and immediate for machine learning and use
  • Immediate Alert function for error parameter setting
  • Input Voltage:  110 VAC (50/60Hz)
  • Power consumption: 220W Max
  • Max Dimension (LxWxH): 400mm(15.7") x 350mm(11.8") x 250mm(9.8")
  • Equipment weight: 48lbs (2.2 kg)
  • Shipping package Weight: 88lbs   (40 kg)
  • 1 Year Warranty
    User Manual is available upon requested
