A123 High Power Nanophosphate LiFePO4 18650 Rechargeable Cell: 3.2V 1100 mAh, 30A Rate, 3.52Wh - UN38.3 Passed

Your Price: $9.95
In Stock

Product ID # 6612
Part Number:
LFP-18650-A123

Personalizations

* denotes required field

Add Tabs ? *


Quantity Discounts

QuantityAmount
5 to 20$9.65
21 to 50$9.45
51 to 100$9.25
101 or more$8.95

Features

Nominal Voltage   3.3V
Nominal Capacity                  1100 mAh (at 0.2C rate, 3.65 +/- 0.05V cut-off)
Energy density 88Wh/kg
Charging current
  • Standard Charging: 1.5A
  • Maximum Charging: 4.0A
Discharging current
  • Maximum Continuous Discharging: 30A
Temperature Range
  • Charging: 0°C to 60°C ambient temp
  • Discharge: -30 oC ~ +60 oC
  • Storage:  -50 oC  ~ +60 oC
Cycle Performance >=1000 (100% of initial capacity at  5.0C discharge)
Dimensions (DxH)   18.2mm(0.7") x 65.15 mm(2.6")
Max Weight 1.41Oz (39 grams)

Warnings

  • Check polarity before use.
  • Don't use NiMH or Li-ion smart charger to charge LiFePO4 cell or pack.
  • Wrong type of charger used will damage the cell. Batteryspace.com will not be responsible for damage
  • LiFePO4 battery must be cut-off at 3.65 +/- 0.05V per cell when charging
  • You must limit discharging rate below recommended Max rate
  • Please read more info about LiFePO4 battery
